View menu
Use this menu to configure the main window display. The options are:
Default Layout Returns all toolbars etc. to default positions.
Size History Only Closes result windows apart from the size history.
Record Views Only Closes the size history, leaving the record views open.
Toolbar Toggles display of the toolbar on/off. A tick appears against this
option when the toolbar is displayed.
Status bar Toggles display of the status bar on/off. A tick appears against this
option when the status bar is displayed.
Measurement Files Toggles display of the measurement files list on/off. A tick appears
against the option when the list is displayed.
Measure menu
Use this menu when ready to make a measurement. Once measurement details
have been entered or an SOP chosen, the Measurement Manager appears.
Start SOP Opens and runs an existing measurement SOP.
Manual Lets the user set up the measurement and spray details manually,
then run a measurement.
Tools menu
Laser control Opens or closes the laser shutter.
Options
}
Serial port... Changes the colours of elements shown in result windows.
Default Size History
View...
Opens the Size History Display dialogue, showing its default
options.
Colours... Changes the colours of elements shown in result windows.
Engineering Used by Malvern service engineers to perform maintenance tasks.
The engineering options are password-protected.
CHAPTER 4
Spraytec
Page 4.16 MAN 0368
