MAN Diesel
MAN B&W S50MC-C8
198 60 79-4.0
Fig. 5.06.02a: Engine outline, S50MC-C8 with turbocharger on exhaust side
317 72 16-4.4.0a
T/C Type a b c
MAN
Diesel
TCA66 2,83 5,536 2,204
TCA77 2,950 5,96 2,460
ABB
TPL73-B CL* 2,700 5,56 2,330
TPL77-B 2,768 5,56 2,260
TPL80-B* 2,75 5,557 2,240
MHI
MET53MA* Available on request
MET60MA 2,839 5,482 2,390
MET66MA
Available on request
MET83MA
Cylinder g L I L II L III
5 3,400 5,924 6,47 6,424
6 4,250 6,774 6,997 7,274
7 5,00 7,624 7,847 8,24
8 5,950 8,474 8,697 8,974
9 Data for 9 cylinders is available on request.
Types of
fore end
Typical for
cylinder no.
Space demand valid for
I
7-8 Basic design
I I
5-6 2nd order moment compensator
I I I
5-6
2nd order moment compensator
and tuning wheel
G
 

,ææçææ,ææçææ,


 

C
  
* Dimension given are only preliminary.
