Fig. 5.06.02b: Engine outline, 6S50MC-C8 with turbocharger on exhaust side
Please note that the latest version of the dimensioned drawing is available for download at www.mandiesel.com under ‘Marine’
→ ‘Low Speed’ → ‘Installation Drawings’. First choose engine series, then engine type and select ‘Outline drawing’ for the actual
number of cylinders and type of turbocharger installation in the list of drawings available for download.
For platform dimensions, see ‘Gallery Outline’.
