Man B&W S50MC-C8-TII - Page 378

MAN B&W 19.10
Page 3 of 11
MAN Diesel
Pos. Description
Mass
(kg) A B C
1 Guide shoe extractor 9.5 420 305
2 Lifting tool for crankshaft 59 230 800 210
3 Lifting tool for thrust shaft 40.6 800 100 126
Fig. 19.10.02: Dimensions and masses of tools
MAN B&W S50MC-C7/8 198 64 31-6.0
31
2
310 15 73-0.4.0
!
"
312 69 54-1.4.0
!
#
"
312 82 03-9.1.0
!
"
