Man B&W S50MC-C8-TII - Page 384

MAN B&W 19.10
Page 9 of 11
MAN Diesel
Pos. Description
Mass Dimensions (mm)
(kg) A B C D E
1 Work table for exhaust valve 180 min. 1,830 1,300 700
2 Suggested working area 1,700 2,150
Fig. 19.10.08: Dimensions and masses of tools
116 55 06-8.1.0
1
#
$
%
!
"
2
MAN B&W S50MC-C7/8 198 64 31-6.0
