MAN B&W 19.10
Page 11 of 11
MAN Diesel
Pos. Description
Mass Dimensions (mm)
(kg) A B C D
1 Collar ring for piston 41.3 350 540 300 850
2 Wave cutting machine for cylinder liner 230 600 1,075
Fig. 19.10.10: Dimensions and masses of tools
122 66 26-9.1.0
21
503 27 57-2.2.0
!
"
MAN B&W S50MC-C7/8 198 64 31-6.0
!
"
#
$
