MAN B&W 19.11
Page  of 
MAN Diesel
198 65 18-1.0MAN B&W S50MC-C7/8
Tool Panels
178 59 48-2.0
Fig. 19.11.01 Tool Panels. 4 88 660
ç ç ç
ç
ç
ç
ç
  





Proposal for placing
of tool panels
Standard sizes of tool panels
Pos. Section Description
Toal mass of tools
and panels in kg
2-900
Cylinder Cover
95
Tool panel incl. lifting chains, grinding mandrels, extractor tools etc.
2 2-904
Cylinder Unit Tools,
284
Tool panel incl. pressure testing tool, piston ring expander, stufng box tools,
templates etc.
3 2-9038
Exhaust valve Tools
58
Tool panel incl. grinding-, lifting-, adjustment- and test tools, etc.
4 2-9042
Fuel oil system Tools
73
Tool panel incl. grinding-, lifting-, adjustment- and assembly tools, etc.
5 2-9030
Control gear Tools
65
Tool panel incl. pin gauges, chain assembly tools, camshaft tools, etc.
6 2-9022
Crosshead and Connection rod Tools
89
Tool panel incl. suspension-, lifting tools, protection in crank case, etc.
7 2-9026
Crankshaft and Thrust bearing Tools
79
Tool panel incl. lifting-, testing- and retaining tools, etc.
