MAINTENANCE CD3340B/YB4411
5-10
Published 04/07/2015 Control # 569-00
p0305
FIGURE 5-2
Mast Bearing
Lube Points
Two Fittings Located on Inside
Surface of Bearing Ring
p0306
FIGURE 5-3
Boom Pivot
Lube Points
p0469
FIGURE 5-4
Retract Chain Roller Lube Points
Both Sides
a0612
FIGURE 5-5
Boom
Head Lube
p0498
p0470
Extend Chain Roller Lube Points
FIGURE 5-6
a0611
Both Sides
Reference Only
