Manitowoc Grove CD3340B User Manual

GROVE 5-11
CD3340B/YB4411 MAINTENANCE
5
Published 04/07/2015 Control # 569-00
p0307
FIGURE 5-7
Lift Cylinder Lube Points
Both Sides
p0308
FIGURE 5-8
Steering Knuckle Lube Points
(Rear Axle)
Both Sides
p0308
FIGURE 5-9
Steering Cylinder Pivot Lube
Points- Rod End (Rear Axle)
Both Sides
p0309
FIGURE 5-10
Steering Cylinder Pivot Lube
Points - Base End (Rear Axle)
p0310
FIGURE 5-11
Steering Link Pivot Lube Points
(Rear Axle)
Both Sides
p0311
FIGURE 5-12
Steering Knuckle Lube
Points (Front Axle)
Reference Only
