Manitowoc Grove CD3340B User Manual

GROVE 11-7
CD3340B/YB4411 STRUCTURAL
11
Published 04/07/2015 Control # 569-00
13. Attach an overhead crane and sling to the telescope
cylinder as shown in Figure 11-9. Raise the 3rd boom
assembly far enough to remove two capscrew (14) and
lockwashers (13). Remove rear slide pad (12).
FIGURE 11-9
P0670
Reference Only
