Figure 4-51 continued
NOTE: For clarity, the counterweight boxes are not shown.
View E
View G
View F
Item Description
1 Shackle (4)
2 Handling Chain (4)
3 Lifting Link (2)
4 Counterweight-Handling Cylinder (2)
5 Inner Connecting Pin (2)
6 Outer Connecting Pin with Safety Pin (4)
7 Counterweight Tray
8 Storage Lug (2)
9 Tie-Down Lugs
