Technical Description General Description
3-2 Sprinter User's Manual
Technical Description
Figure 3-1 is the view from the front left side of the SprinterB Printer.
Figure 3-1: General View of the Front and Left Side of the Printer
Figure 3-2 is the view from the rear right side of the SprinterB Printer.
Figure 3-2: General View of the Rear & Right Side of the Printer
Top Cover
Substrate Pass Door
Service Doors
Emergency Stop
Button
Electric Power Switch
Pneumatic Quick Connector
Rear Cove
r
PC Doo
r
Emergency
Stop Button
Collector Roller
Front Cover
