Matan The SprinterB - Figure 3-6: Liquid Coolant Pumped to the Aluminum Profiles; Figure 3-7: the Ribbon and Substrate Flow; The Ribbon System

General Description Technical Description
Sprinter User's Manual 3-5
Figure 3-6: Liquid Coolant pumped to the Aluminum Profiles
The Ribbon System
The RIBBON SYSTEM, as illustrated in Figure 3-7and Figure 3-8, page 3-6,
comprises the R
IBBON and the RIBBON TAKE-UP ROLL.
Figure 3-7: The Ribbon and Substrate flow
Four Aluminum Profiles
