Matan The SprinterB - Figure 3-3: the Main Power Connector; Figure 3-4: Power Supply Units; Power Supply Units; The Power Inlet Connection

General Description Technical Description
Sprinter User's Manual 3-3
The Power Inlet Connection
The printer is supplied with a MALE POWER CONNECTOR and should be
connected to the F
EMALE POWER CONNECTOR (also supplied,) that has been
connected to the power box by an authorized technician.
Figure 3-3: The Main Power Connector
Power Supply Units
The printer has four or eight POWER SUPPLY UNITS. They are located on the
right side of the printer, behind the S
ERVICE DOORS FOR TECHNICIAN
(Figure 3-2, page 3-2),as illustrated below.
Figure 3-4: Power Supply Units
(
4 or 8
)
Power Su
pp
l
y
Units
