Preparing Your Printer for Printing Operating the Substrate Collecting System
Sprinter User's Manual 8-11
Operating the Substrate Collecting System
The Printer can be operated either with or without the SUBSTRATE
C
OLLECTING SYSTEM operating (Figure 8-12). The COLLECTING MECHANISM
can operate separately from the printer (Figure 8-13).
Figure 8-12: The Substrate Collecting System
Figure 8-13: The Substrate Collecting Mechanism
Substrate
Collecting
Mechanism
Collector
Roller
Guiding
Roller
