Preparing Your Printer for Printing Software Preparations for Printing
Sprinter User's Manual 8-29
Setting the Encoder Division
The ENCODER sends pulses to the MAIN MOTOR.
Set the E
NCODER PARAMETER according to the following table:
Printer Type Motor Type Encoder Location Encoder Parameter
Sprinter A On the Rubber Roller 7
SprinterB 36/40 Small Motor On the Motor 202
SprinterB 36/40 Large Motor On the Motor
194
SprinterB 36/40 On the Rubber Roller 7
Main Motor Coefficient
The MAIN MOTOR COEFFICIENT controls the speed of the MAIN MOTOR.
Set the M
AIN MOTOR COEFFICIENT PARAMETER according to the following
table:
Printer Type Main Motor Coefficient Parameter
Sprinter A 1
SprinterB 36/40 ~5.4*
*This parameter is subject to change, based on speed tests performed in
the C
ONTROL dialog box, in order to obtain 60m/hr at "ultra" speed mode.
As an example, if the print test results show 65m/hr., then
THE MAIN
MOTOR COEFFICIENT PARAMETER must be reduced. This parameter should be
adjusted in order to give a maximum speed of 60m/hr.
Selecting the Y Resolution
Select the Y Axis resolution according to the following options:
Printer Type Y Resolution Option
Sprinter A 400 x 400 dpi
SprinterB 36/40 400 x 400 dpi, 400 x 200 dpi
