Preparing Your Printer for Printing Software Preparations for Printing
Sprinter User's Manual 8-27
The recommended moment for the Ribbon Collecting Roll is 4-5, when the core
is empty and 5-6 when it is full.
Loading and unloading the Substrate
! To load the Substrate:
• In the C
ONTROL dialog box, click LOAD.
The SprinterB will run a set of operations and will bring the printer to
the print mode, with the setting specified in the C
ONFIGURATION dialog
box.
Alternatively, when you click P
RINT, the loading process will
automatically be initiated befoe the printing process.
! To unload the Substrate:
• In the C
ONTROL dialog box, click UNLOAD. Or, click the UNLOAD icon in
the M
AIN SCREEN.
The printer returns from the print mode.
Reactivating the 24v
! To reactivate a 24v voltage:
• As soon as you open the C
ONTROL dialog box, the power is
automatically activated.
If no operation is carried out after one minute of opening the C
ONTROL
dialog box, the power will be shut off.
