Page 64
The controls at all remote control stations will operate as
outlined when in the Troll Mode.
Troll Mode 'ON'/'OFF'. One (1) switch at the Master Control
Station can be used to turn Troll Mode 'ON' or 'OFF'. When in
the 'OFF' position there is no clutch slip.
The system is designed such that the operator cannot
mishandle the controls to damage the transmission.
A consideration is the installation of a propeller shaft
tachometer. It is the best way of knowing your propeller
speed when you are in the Troll Mode.
Requirements:
1) The trolling valve lever load should not exceed 40 lbs.
(18kg)
2) The Trolling Valve Actuator requires a reliable battery
source of 12 to 32 volts DC.
NOTE: It is important to complete the installation of the clutch and throttle control
and to thoroughly test the system before installing the Trolling Valve
Control.
20.3 PARTS REQUIRED
20.3.1 Supplied By Your MicroCommander Dealer
1 only 813 Actuator Trolling (Twin Screw)
1 only 1133 Auxiliary Board Kit (Lead) Port
1 only 1135 or 1135-1 Auxiliary Board Kit (Follow) Starboard
1) The Auxiliary Boards are to be installed in the 585
Actuators.
2) A ferrite bead for the power cable is included with the
Trolling Valve Actuator.
Eight (8) Conductor Shielded Cable Pc.No. 180
500' spool Pc.No. 350
Two (2) Conductor Power Cable Pc.No. 212
250' spool Pc.No. 349
