NOTE: Either engine can be 'Lead' engine. We have elected to make the Port
engine 'Lead' and the Starboard engine 'Follow'. The drawings and
explanation reflect this selection. The remote control stations will have the
green LED synchronization light on the Starboard side.
19.3 INSTALLATION
A) Remote Control Stations - Connect the violet lead to terminal
8 at each Starboard remote station lever that has a green
LED.
NOTE: The control head part number followed by a -2 specifies one (1) green LED
on the 'Follow' control head. If you are adding synchronization to an
existing system you may not have the green LED. The system will
synchronize without the light, however, you won't have a visual indication of
synchronization.
B) Auxiliary Board 1133 'Lead' Port 585 Actuator - The kit
includes the Auxiliary Board, mounting screws, and a ¾" cable
grip. Install the cable grip for the cross over lead. Install the
Auxiliary Board to the plug connector and secure with screws.
C) The Auxiliary Board for the Starboard 585 Actuator is either
Pc.No. 1135 (for a diesel engine) or Pc.No. 1135-1 (for a gas
engine). The kit includes the Auxiliary Board, mounting
screws, a ¾" cable grip, and two (2) only ½" cable grips.
Install the cable grips, and then the Auxiliary Board to the
plug connector using the mounting screws.
D) Connect the violet conductor in the Starboard Actuator for
station 1, 3, or 5 to Terminal 1, 2, or 3 of TB4. Connect the
violet lead for station 2 or 4 to Terminal 7 or 8 of TB1. (See
Sync Circuit Dwg. 0486-A)
E) Run a length of eight (8) conductor cable between the
Actuators using the ¾" cable grips, and connect the green lead
to Terminal 6 of TB1 in each Actuator. Connect the eight (8)
conductor drain wire to the Auxiliary Board mounting screw
on one (1) Actuator. Do not connect the other end
To Next Page
