Page 60
transmission and place shift levers in 'NEUTRAL'. 'Start' the
engines and move the controls ahead beyond shift to
approximately 1500 RPM. The green LED should blink, and
the engines synchronize.
NOTE: Engines will not synchronize unless shifted to 'AHEAD' and above 10% of
speed range. The engines should synchronize. If they do not, make the
CHECKS listed below.
19.4 OPERATION CHECKS
A) Check wiring connections (Dwg.No.0486-A)
B) Check that the 'Lead' and 'Follow' are correct entering the
'Follow' Actuator.
C) Check for 3.Ø AC volts or greater between Terminals 2 and 3
on TB2 and TB3 Auxiliary Board 1135 or 1135-1. This with
the engines idling.
