POWERHEAD
Page 4A-20 90-855347R1 JANUARY 1999
CRANKCASE COVER REMOVED
51848
1. Use Powerhead Stand (91-30591A1) for rotating crankshaft to desired position for re-
moval of connecting rods.
2. Using an awl or electric pencil, scribe the cylinder identification number on each con-
necting rod as shown. Reassemble connecting rods in same cylinder.
51849
3. Use a 5/16 in. 12 point socket to remove connecting rod bolts, then remove rod cap,
roller bearings and bearing cage from connecting rod.
51850
a
a-Connecting Rod Bolts
4. Push piston out of cylinder block.
5. After removal, reassemble each piston and connecting rod assembly.
