Mercury Optimax 115

LEFT HAND NON-RATCHETING
90-855347R1 JANUARY 1999 Page 6B-9
Gear Housing (Prop Shaft)(Counter Rotation)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 GEAR HOUSING (BLACK)(BASIC)
51 1 CAM FOLLOWER
52 1 SHIFT CAM
53 1 ROD
54 AR SHIM SET
55 1 BEARING ADAPTOR ASSEMBLY
56 1 ROLLER BEARING
57 1 THRUST WASHER
58 1 THRUST BEARING
59
1 REVERSE GEAR (1.87:1 – 15/28)(150)
59
1 REVERSE GEAR (2:1 – 14/28)-(135)
60 1 ROLLER BEARING
61 1 SPRING
62 1 SLIDING CLUTCH
63 1 CROSS PIN
64 1 DETENT PIN
65 1 PROPELLER SHAFT
66
1 FORWARD GEAR (1.87:1 – 15/28)(150)
66
1 FORWARD GEAR (2:1 – 14/28)-(135)
AR SPACER SHIM .206 IN.
AR SPACER SHIM .208 IN.
AR SPACER SHIM .210 IN.
AR SPACER SHIM .212 IN.
AR SPACER SHIM .214 IN.
AR SPACER SHIM .216 IN.
67 AR SPACER SHIM .218 IN.
AR SPACER SHIM .220 IN.
AR SPACER SHIM .222 IN.
AR SPACER SHIM .224 IN.
AR SPACER SHIM .226 IN.
AR SPACER SHIM .228 IN.
AR SPACER SHIM .230 IN.
