MI 3152(H) EurotestXC (2,5 kV) Tests and measurements
137
Figure 7.67: Examples of Harmonics measurement results
Measurement results / sub-results
U:h(i)
TRMS voltage of selected harmonic [h0 ... h11]
I:h(i)
TRMS current of selected harmonic [h0 ... h11]
THDu
Voltage total harmonic distortion
THDi
Current total harmonic distortion
