MI 3152(H) EurotestXC (2,5 kV) Appendix B – Profile notes
193
A.2 Profile Hungary (profile code ALAD)
Fuse type gR added to the fuse tables. Refer to Fuse tables guide for detailed information on
fuse data.
New Single test function Visual Test added.
Figure A.1: Visual Test menu
Measurement parameters / limits
Protection type [No, Automatic disconnection, Class II,
Electrical separation, SELV,PELV]
Measurement procedure
Enter the Visual Test function.
Set test parameters / limits.
Perform the visual inspection on tested object.
Use to select PASS / FAIL / NO STATUS indication.
Save results (optional).
Figure A.2: Examples of Visual Test result
Modifications in chapter 7.8 RCD Auto – RCD Auto test
Added tests with multiplication factor 2.
