METREL EurotestXC MI 3152 User Manual

MI 3152(H) EurotestXC (2,5 kV) Tests and measurements
159
7.30 Locator
This function is intended for tracing mains installation, like:
 Tracing lines,
 Finding shorts, breaks in lines,
 Detecting fuses.
The instrument generates test signals that can be traced with the handheld tracer receiver
R10K. See Appendix C – Locator receiver R10K for additional information.
Figure 7.99: Locator main screen
Typical applications for tracing electrical installation
Figure 7.100: Tracing wires under walls and in cabinets
Figure 7.101: Locating individual fuses
