MI 3152(H) EurotestXC (2,5 kV) Instrument operation
29
4.4.4 Result indication
Measurement result is inside pre-set limits (PASS).
Measurement result is out of pre-set limits (FAIL).
Measurement is aborted. Consider displayed warnings and messages.
RCD t and RCD I measurements will only be performed if the contact voltage
in the pre-test at nominal differential current is lower than the set contact
voltage limit!
4.4.5 Auto Sequence® result indication
All Auto Sequence® results are inside pre-set limits
(PASS).
One or more Auto Sequence® results are out of pre-
set limits (FAIL).
Overall Auto Sequence® result without PASS / FAIL
indication.
Measurement result is inside pre-set limits (PASS).
Measurement result is out of pre-set limits (FAIL).
Measurement result without PASS / FAIL indication.
Measurement not performed.
