METREL EurotestXC MI 3152 User Manual

MI 3152(H) EurotestXC (2,5 kV) Auto Sequences 
167
8.2.1.3 Indication of Loops
The attached ‘x3’ at the end of single test name indicates that a loop of single tests is
programmed. This means that the marked single test will be carried out as many times as the
number behind the ‘x’ indicates. It is possible to exit the loop before, at the end of each
individual measurement.
8.2.2 Step by step execution of Auto Sequences®
While the Auto Sequence® is running it is controlled by pre-programmed flow commands.
Examples are:
- pauses during the test sequence
- proceeding of test sequence in regard to measured results
- etc.
Figure 8.6: Auto Sequence® – Example of a pause with message
Figure 8.7: Auto Sequence® – Example of a finished measurement with options for
proceeding
Options (during execution of an Auto Sequence®)
Proceeds to next step in the test sequence.
Repeats the measurement.
Displayed result of a single test will not be stored.
