MI 3152(H) EurotestXC (2,5 kV) Single tests
79

Accepts the new parameters and limit
values and exits.
6.1.3 Single test start screen
Figure 6.2: Single test start screen, example of insulation resistance measurement
Options (before test, screen was opened in Memory organizer or Single test main menu)
Starts the measurement.
long
Starts the continuous measurement (if applicable on
selected single test).
long
Opens help screens.
on
Opens menu for changing parameters and limits.
Refer to chapter 6.1.2 Setting parameters and
limits of single tests for more information.
long on
Enters cross selector to select test or measurement.
Expands column in control panel.
