micro-trak SprayMate II - Appendix E: Radar Adapter Cables

50
DICKEY-john Radar Packard Connector
In-Cab John Deere "Y" Cable
DICKEY-john Radar Ford Connector
Vansco Radar Amp Connector
DICKEY-john Radar Amp Connector
DICKEY-john Radar Deutsch Connector
1. Ground
2. Signal
3
. +12 Volts
4. N/C
1. +12 Volts
2. Ground
3. Signal
4. Enable
A. Ground
B. Signal
C. 12 Volts
D. 12 Volts
A. 12 Volts
B. 12 Volts
C.
S
ignal
D. Ground
1. 12 Volts
2. +12 Volts
3.
S
ignal
4. Ground
1. Ground
2.
S
ignal
3. +12 Volts
4. Enable
S
ignal
G
round
C
ommon
1.
G
r
ound
2. 12 Volts
3. Signal
DICKEY-john Radar Cannon Connector
Magnavox & Phillips Radar Packard Connector
R
a
v
en Radar Conxall Connector
RADAR CONNECTOR SIGNAL PIN
DICKEY-john Amp 2
D
ICKEY-john Cannon 3
DICKEY-john Deutsch 3
DICKEY-john Ford 2
D
ICKEY-john Packard B
In-Cab JD (8000 & 9000’s) Metri-Pak A
Magnavox & Phillips Packard C
Raven Conxall 3
Vansco Amp 2
P/N 14926
Appendix E: Radar “Y” Adapter Cables
In-Cab John Deere Metri-Pak Connector
8000/9000 Series
