micro-trak SprayMate II - Component Parts and Assembly Hardware

5
Component Parts and Assembly Hardware
B
efore beginning installation, check the carton contents for the following items:
Owner’s Manual
P/N 14943
Console Mount Kit
P/N 13181
C. 15' 3-Pin Extension Cable
M/P 150 P/N 13207
C
B
A
C
B
A
B. 14” Nylon cable ties (10)
P/N 12910
F. Hardware Bag
P/N 13251
D
.
Speed sensor
moun
ting bracket
P/N 10013
E. Magnets (6) P/N 12069
(2 in har
dware bag)
A B C
A.
5' Hall-effect Speed/Flow
Sensor Cable P/N 13096
SprayMate
™
II Console
P/N 14869
S
p
eed S
ensor Kit P/N 01531 (1)
Including items A-F, below:
A
B
C
5' Hall-effect Flow Sensor Cable
with threaded sensor
P/N 13096
FM750 GFN (P/N 11501)
Flowmeter
M-T 1” Electric Servo Valve
P/N 14928
SprayMate
II
AU
T
OMAT
IC
RAT
E
C
O
NTR
O
LLE
R
R
EFER
ENC
E
MAN
UAL
