micro-trak SprayMate II - NH3 System Layout

53
Appendix G: SprayMate II System Layout for NH3
P/N 14361
P/N 14315
P/N 14311
Gray Tie
Yellow Tie
Yellow Tie
Yellow Tie
Yellow Tie
Remote Speed Access NOTE: If using Remote Access, Local
Speed Access Cable Must be
Connected as Shown
P/N 13273, (nor
mally pr
e-
installed on
Plumbing Panel)
Local Speed Access, use
Extension Below
P/N 13207, 180" 3-wire
Extension
Connect Together if Remote
Speed Access is Used
