micro-trak SprayMate II - NH3 Specific Component Parts

54
Before beginning installation, check the carton contents for the following items:
Console Mount Kit
P/N 13181
Appendix G: SprayMate II - NH3 Specific
Component Parts & Assembly Hardware
Owner’s Manual
P/N 14943
SprayMate
™
II Console
P/N 14869
SprayMate
II
A
U
T
O
MA
T
IC RA
T
E
CO
NTRO
LLER
REFERENC
E
MANU
AL
Instructions
Terminal Kit
P/N 13632
A
B
C
C
B
A
C
B
A
Hall-eff
ec
t S
p
eed/Flow Sensor
Cable P/N 13096
15' 3-pin M/P 150 Extension Cable
P/N 13207
Speed Sensor Mounting Bracket
P/N 10013
Hardware Bag
P/N 13251
M
agnets (6)
P/N 12069
(2 in hardware bag)
14" Nylon Cable Ties (10)
P/N 12910
Speed Sensor Kit P/N 01531 (1)
Includes items below
Power Cable
P/N 14315
Run/Hold
Switch Kit
P/N 14361
Optional Power
Switch Kit
P/N 14360
10 ft. NH3 Adapter Cable
P/N 14311
