7 TECHNICAL DATA
7.1 TECHNICAL DATA TX/RX BARS
Internal power supply (range of measurement from 1 to 5 m)
Rechargeable Li-ion battery 7.4V 1800mAh
External power supply (range of measurement from 1 to 10 m)
24VDC ±5%
Infrared wave length
890 nm
Number of optical sensors
96 per meter
Space resolution
1.041mm
Sensor height (from the optical centre of the sensor to the
lower edge)
3mm
Time accuracy
1 millisecond
Operational temperature
0°C ~ +35°C
Storage temperature
-25°C ~ +70°C
Max. distance between transmitter (Tx) and receiver (Rx)
6m
Dimensions of TX - RX with integrated interface
1100mm x 100mm x 100mm (W x D x H)
Dimensions of Tx - Rx
1000mm x 100mm x 45mm (W x D x H)
Dimensions of Tx - Rx with integrated interface
2kg
Weight of additional Tx and Rx bars
1.5kg
