4.2.2.5 TREADMILL RUNNING TEST
Main Parameters
 Start type: this can only be ‘Software command’ or ‘External Impulse’
 Stop type: this can be ‘Software command’, 'End of Time' or ‘External Impulse’
 Starting foot: see above
 Test length: appears only if Stop type = ‘End of Time’ and specifies how many
minutes:seconds the test must last (from 00:01 to 59:59)
 Treadmill speed: indicates the speed in km/h the treadmill is set at; the setting range is 0.1-
20.0 km/h with steps of 0.1.
 Direction: indicates if the walking direction is 'Interface side' or 'Opposite side'. Therefore, if
the interface drums are at the end of the treadmill choose 'Opposite Side', or vice versa.
Figure 51 - Direction: OPPOSITE Side
Figure 52 - Direction: IINTERFACE Side
Secondary Parameters
 Minimum contact time [ms]: see above
 Minimum flight time [ms]: see above
 Maximum flight time [ms]: see above
 Step length calculation: see above
 Minimum gap between feet [cm]: see above
 Minimum foot length [cm]: see above
 Filter GaitR IN and Filter GaitR OUT [LED]: see above
