5.1.3 SPRINT/GAIT TEST
The following are some useful definitions to explain the values displayed on the table with numerical
data.
Step: the distance between the tip (toe) of two subsequent feet or the distance between the heel
of two subsequent feet depending on the settings in the parameter ‘Step length calculation’ (see
chap. 4.4.1.5).
Figure 109 - Step definition
Stride: the distance between the tip of two subsequent footprints of the same foot or the distance
between the heel of two subsequent footprints of the same foot depending on the settings in the
parameter ‘Step length calculation’ (see chap. 4.4.1.5).
Figure 110 - Stride definition
Speed: is the relation between the distance between the two feet and the sum of the first Contact
time (Tc) and the Flight time (Tf).
