PRE INSTALLATION
Milli-Q Synthesis/Synthesis A10 17
3-3 OPTIONAL EQUIPMENT YOU MAY NEED
WALL MOUNTING BRACKET
The Millipore Catalogue Number for the Wall Mounting Bracket is SYSTFIX01. The mounting hardware
for attaching the bracket to a wall is not included and must be supplied. The bracket is attached with at least 2
bolts (or screws).
Width of bracket = 23 cm Height of bracket = 5.4 cm
Thickness of bracket = 0.4 cm Diameter of holes in the bracket for bolts or screws = 0.7 cm
Mounting holes on bracket are approximately 5.4 cm from either edge
PRESSURE REGULATOR
The Millipore Catalogue Number for a Pressure Regulator (with Pressure Gauge and 8 mm tubing connections) is
ZFMQ000PR.
It is important that the Pressure Regulator is adjusted while water is
flowing through it. A range between 0.1 bar and 0.3 bar (1.5 to
4.5 psi) is the normal setting of the Pressure Regulator while water
is being dispensed from the Milli-Q. The Pressure Regulator is
factory pre-set to 0.3 bar while water at 80 LPH is flowing through
it.
BALL VALVE FOR SHUTTING OFF THE FEEDWATER SUPPLY
It is highly recommended to use a ball valve on the Feedwater Tubing. The ball valve will be used to shut off the
Feedwater Supply if necessary.
Contact Millipore for information regarding the ball valve. It is usually necessary to have fittings installed on both
ends of the ball valve to be able to connect it to the Feedwater Tubing.
REMOTE POINT OF USE DISPENSER
A Remote POU Dispenser can be added to the Milli-Q. This allows you to dispense water a maximum distance of
2.5 meters away from the Milli-Q. The Remote POU Dispenser is rested on a moveable arm that allows 180
rotation.
The Millipore Catalogue Number for a Remote POU Dispenser (plus arm and weighted base) is
ZMQSP0UR1. It is also necessary to order an installation kit with the Remote POU Dispenser. This
Installation Kit has a Millipore Catalogue Number of ZMQSP0U01.
The Remote POU Dispenser can be either wall mounted or set on a benchtop. The Installation Instructions for the
Remote POU Dispenser are included with it.
ATTENTION
