PRE INSTALLATION
Milli-Q Synthesis/Synthesis A10 20
3-4 INSTALLATION REQUIREMENTS
CONSUMABLES NEEDED FOR INSTALLATION
You will need one Q-Gard Pack, Quantum Cartridge and Millipak for installation. These items do not come with
the Milli-Q system. These items need to be ordered separately. The Catalogue Numbers and options for these
items are written below.
Some of the items below can be ordered as part of a kit. An example might be a kit consisting of a particular type
of Quantum Cartridge plus a Millipak Express 20. See Section 8-1 for the catalogue numbers and descriptions of
various kits.
See Section 2-3 for technical information regarding the Consumables for a Milli-Q system.
Q-Gard Purification Pack
 Q-Gard 1 QGARD00R1 1/box (RO, Elix, distilled, Milli-RX, Milli-RO feedwater)
 Q-Gard 2 QGARD00D2 1/box (DI, Service DI feedwater)
Quantum Ultrapure Cartridge
 Quantum IX QTUM000IX 1/box
(100% Ion Exchange Resin)
 Quantum EX QTUM000EX 1/box
(Ion Exchange Resin + media for Organics removal)
 Quantum VX QTUM000VX 1/box
(Volatile Organics removal + ion exchange resin)
Quantum Ultrapure Cartridge with 1 non sterile Millipak 20 Express
 Quantum IX QTUMMPEIX 1/box
 Quantum EX QTUMMPEEX 1/box
Millipak 40 Final Filter
 Millipak 40 (sterile) MPGL04SK2 2/box
Millipak Express 20 Final Filter
 Millipak Express 20 (non sterile) MPGP02001 1/box
SPACE AND WEIGHT REQUIREMENTS
See Section 2-4 for a drawing showing the dimensions of a Milli-Q.
 Total Height needed (includes POU Dispenser being fully upright): 53 cm
 Total Width needed (includes room needed to remove Q-Gard): 45 cm
 Total Depth needed (includes POU when it is fully upright): 53 cm
 Operating weight for a ‘wet’ Milli-Q Synthesis (Synthesis A10): 16 kg (16.8 kg)
ELECTRICAL REQUIREMENTS
 The electrical requirements for a Milli-Q Synthesis (or Milli-Q Synthesis A10) are:
120 VAC  10%, 50/60 Hz, 100 VA, 0.5 amp source, 2 amp Time Lag fuse used (ref. ZMQS6VFT1,
ZMQP6VFT1, ZMQS6VF01, ZMQP6VF01).
230 VAC  10%, 50/60 Hz. 0.26 amp source, 1 amp Time Lag fuse used (ref. ZMQS5VFT1,
ZMQP5VFT1, ZMQS5VF01, ZMQP5VF01).
 The source of electrical power should be within 1 meter of the Milli-Q. The source of electrical power must be
earth grounded.
