PROGRAMMING CHART 4
PARAMETER ALTERED VALUES FOR POINT #’s
#NAME 1 2 3
ADVANCED ECHO PROCESSING
P810 Scope Displays (G)
P816 Echo Time
P817 Profile Pointer Time
P818 Profile Pointer Distance
P819 Profile Pointer Amplitude
P820 Algorithm
P821 Spike Filter
P822 Narrow Echo Filter
P823 Reform Echo
P824 (reserved)
P825 Echo Marker Trigger
P830 TVT Type
P831 TVT Shaper
P832 TVT Shaper Adjust record values on a separate sheet
P833 TVT Start Min
P834 TVT Start Slope
P835 TVT Slope Min
P840 Short Shot Number
P841 Long Shot Number
P842 Short Shot Frequency
P843 Long Shot Frequency
P844 Short Shot Width
P845 Long Shot Width
P850 Short Shot Bias
P851 Short Shot Floor
P852 Short Shot Range
TEST
P900 Software Rev. # (V) (G)
P901 Memory (V) (G)
P902 Watchdog (V) (G)
P903 Display (V) (G)
P904 Keypad (G)
P905 Transmit Pulse (V)
P906 Communications (G)
P907 Programmer Interface (G)
P908 Scanner (G)
P910 Relay (G)
P911 mA Output Value
P912 Transducer Temperature (V)
P913 Sensor Temperature (V)
MEASUREMENT AND SIMULATION
P920 Reading Measurement (V)
P921 Material Measurement (V)
P922 Space Measurement (V)
P923 Distance Measurement (V)
P924 Volume Measurement (V)
MASTER RESET
P999 Master Reset
■
