PERFORMANCE TEST RESULTS
Monitor system performance carefully, under all anticipated operating conditions.
A. If the DPL+ performs exactly as required, copy all Parameter Value alterations to the
PROGRAMMING CHARTS in the back of this instruction manual. (Altered Parameter Values may
be scroll accessed). No further action is required. The DPL+ will continue performing reliably, with
little or no maintenance.
B. If a measurement difficulty is encountered (the "LOE" display persists after start up), or
performance does not meet installation requirements, proceed to the .
C. If the DPL+ provides accurate and repeatable measurements, however alternate Reading units,
failsafe action, relay, or mA output operation is desired, proceed to .
If all operating conditions cannot be observed during the System Performance Evaluation, refer to
Reading Measurement (P920). Perform a Reading Measurement
simulation to verify programming.
Ensure the PROGRAMMING CHARTS are altered accordingly, and a new System Performance Evaluation
is conducted, following any operation alteration or measurement difficulty remedy.
Connect (or enable) process control / alarm equipment to the DPL+ only after
satisfactory performance is verified for all possible operating conditions.
APPLICATION PARAMETERS
TROUBLESHOOTING GUIDE
ENHANCEMENT PARAMETERS
PL-508 30
