SCANNING PARAMETERS (P725 to P729)
P725 AUXILIARY TRANSDUCER
Use this feature when a long range transducer is used, but the Nearest Distance (see
INSTALLATION Transducer Mounting) of a short range transducer is required.
(2 transducers per vessel).
In the RUN mode, if the material level is within the short range transducer measurement range,
that measurement is processed. Otherwise, the long range transducer measurement is used.
With the long range transducer Point Number displayed, enter the short range Point Number.
values: 0 = not required (preset)
1 = Auxiliary Transducer is Transducer 1
2 = Auxiliary Transducer is Transducer 2
P726 LEVEL SYSTEM SYNC
Use this feature if another level measurement system is mounted near the DPL+.
See Interconnection / Level System Synchronization.
values: 0 = not required
1 = synchronize level monitors (preset)
P727 (G) SCAN DELAY
Use this feature to adjust the delay before the next point is scanned.
Enter the amount of delay in seconds.
This value is automatically altered when Measurement Response (P003) is altered.
(See TECHNICAL REFERENCE Measurement Response).
values: 0.000 to 60.00
P728 SHOT DELAY
Use this feature if transient acoustic noise within the vessel is causing measurement difficulties.
This value is automatically altered when Measurement Response (P003) is altered.
(See Measurement Response.
Enter the delay between transmit pulse shots (in seconds).
values: 0.1 to 4.0
P729 (V) SCAN TIME
View the time elapsed (in seconds) since the point displayed was last scanned. This value
may be viewed as an Auxiliary Reading in the Run mode. See keypad.
values: 0.000 to 9999
