– 3.38 –
With no area specified
Cutting order
With area specified
Specified
area
Cutting
order
Sorting sequence
1. Data are being transmitted.
Unprocessed data size in the receiving buffer is dis-
played. Cutting is not conducted. The processed line
segments are stored in the sorting buffer.
2. Data transmission completes.
Waiting time required to start cutting (Remaining time
is displayed in seconds)
If no data is received during the waiting time, the
counter starts counting down. The waiting time can be
changed in the [CLOSE TIME] of the communication
conditions.
3. Auto-feed is executed.
Before starting cutting, the sheet is drawn by the length
of data to be cut. If the sheet is not long enough to
cover the whole data, the error shown below is dis-
played.
After changing to a long sheet, transmit data or execute
piece-cutting.
*SORTING* 1%
CUT1 ** 2KB**
**PLOT** 5S
ERR15 AUTOFEED
