Introduction Replacement Parts
7 - 16 046-006272-00 A7™ Service Manual
7.1.2.10 Vaporizer Mounting Minifold
FIG.NO. DESCRIPTION PART NUMBER
1 Connector (Vaporizer Mount) 801-0631-00117-00
2 Valve of Vaporizer Mounting Manifold 801-0631-00106-00
3 Spring of Vaporizer Mounting Manifold 801-0631-00107-00
4 Locking plate 041-000166-00
5 Locking pin 0611-20-45417
6 Spring, special for vaporizer, S type M6T-010009---
1
2
3
4
5
6
