Mindray A9 Operating Instructions

Cleaning and Disinfection Maintenance
9 - 18 Operator’s Manual of Anesthesia System
Figure 9-18 Put out the volume exchanger
3. Close the volume exchanger cover.
9.7.3.1.11 Visual Inspection
After the disassembly, inspect the following components for damage, wear and tear, and the visual
inspection criteria is no damage, no creak, no distortion.
•Volume Exchanger
• Breathing System Body
• Bag Arm
•O
2
sensor support
•Bypass
•CO
2
Absorbent Canister
• Inspiration connector
• Expiration connector
• Flow sensors
•Inspiration valve
• Expiration valve
• Seals and sealing rings
If the components are damaged, worn and torn, contact your service personnel or Mindray.
9.7.3.2 Cleaning and Disinfection (Choose One)
9.7.3.2.1 Manual Cleaning
1. Submerge or rinse the Breathing System in an authorized cleaning agent (See Table 9-3 "Manual
Cleaning Agent" on Pages 9-9) for the required period as specified by the manufacturer of the
cleaning solution.
2. Rinse the Breathing System with the clean water.
3. Completely dry the Breathing System before use.
4. To disinfect the Breathing System, proceed to following steps. Otherwise, jump to 9.7.3.4
Reassembly.
Volume exchanger

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
