Mindray A9 Operating Instructions

Operator’s Manual of Anesthesia System 10 - 17
Product Specifications Monitor Module
Rise Time (10% to 90%) Gas Measured by using
adult/pediatric water
trap and 2.5m
sampling line
Measured by using
neonatal water trap
and 2.5m sampling
line
CO
2
≤250ms@150ml/min
≤250 ms@180ml/min
≤250 ms@200ml/min
≤250 ms@100ml/min
≤250 ms@110ml/min
≤250 ms@120ml/min
N
2
O ≤250ms@150ml/min
≤250 ms@180ml/min
≤250 ms@200ml/min
≤250 ms@100ml/min
≤250 ms@110ml/min
≤250 ms@120ml/min
O
2
≤500ms@150ml/min
≤500ms@180ml/min
≤500ms@200ml/min
≤600ms@100ml/min
≤600ms@110ml/min
≤600ms@120ml/min
ENF ≤350ms@150ml/min
≤350 ms@180ml/min
≤350 ms@200ml/min
≤350 ms@100ml/min
≤350 ms@110ml/min
≤350 ms@120ml/min
HAL, DES, SEV,
ISO
≤300ms@150ml/min
≤300 ms@180ml/min
≤300 ms@200ml/min
≤300 ms@100ml/min
≤300 ms@110ml/min
≤300 ms@120ml/min
System Total Response Time Gas Measured by using
adult/pediatric water
trap and 2.5m
sampling line
Measured by using
neonatal water trap
and 2.5m sampling
line
CO
2
≤5 s @150ml/min
≤5 s @180ml/min
≤5 s @200ml/min
<6 s @100ml/min
<6 s @110ml/min
<6 s @120ml/min
N
2
O ≤5 s @150ml/min
≤5 s @180ml/min
≤5 s @200ml/min
<6 s @100ml/min
<6 s @110ml/min
<6 s @120ml/min
O
2
≤5 s @150ml/min
≤5 s @180ml/min
≤5 s @200ml/min
<6 s @100ml/min
<6 s @110ml/min
<6 s @120ml/min
DES, SEV, ISO,
HAL, ENF
≤5 s @150ml/min
≤5 s @180ml/min
≤5 s @200ml/min
<6 s @100ml/min
<6 s @110ml/min
<6 s @120ml/min
Primary agent ID threshold
3
0.15% (0.4% during ISO accuracy mode)
Secondary agent ID
threshold
4
0.3% (0.5% during ISO accuracy mode) or 5%
REL
(10%
REL
for Isoflurane)
of primary agent if Primary agent >10%
Measurement accuracy drift Meets accuracy requirements within 6 hours
Rate measurement Measurement range: 2 bpm to 100 bpm
Resolution: 1 bpm
Measurement accuracy:
2 bpm to 60 bpm: ± 1 bpm
61 bpm to 100 bpm: ± 2 bpm
1. Experiment condition: temperature of sampled gas is 37 °C, ambient temperature is 23 °C, relative humidity
of sampled gas is 100%.
2. Cleaning time of watertrap ≥24h means that the liquid level will not exceed the MAX line within 24 hours.
3. For Halothane: Increase in threshold by 0.1%
ABS
.
4. For Halothane: Increase in threshold by 0.1%
ABS
.
TABLE 10-23 AG Module

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
