Mindray A9 Operating Instructions

Operator’s Manual of Anesthesia System A - 3
Accessories
Gas Supply
Hoses
0004-00-0077-11 O2 Gas Supply Hose, 15 ft, Ohmeda
0004-00-0077-12 O2 Gas Supply Hose, 15 ft, Chemetron
0004-00-0077-13 O2 Gas Supply Hose, 15 ft, Puritan Bennett
0004-00-0077-14 O2 Gas Supply Hose, 15 ft, DISS Female
0004-00-0078-11 N2O Gas Supply Hose, 15 ft, Ohmeda
0004-00-0078-12 N2O Gas Supply Hose, 15 ft, Chemetron
0004-00-0078-13 N2O Gas Supply Hose, 15 ft, Puritan Bennett
0004-00-0078-14 N2O Gas Supply Hose, 15 ft, DISS Female
0004-00-0079-11 Air Gas Supply Hose, 15 ft, Ohmeda
0004-00-0079-12 Air Gas Supply Hose, 15 ft, Chemetron
0004-00-0079-13 Air Gas Supply Hose, 15 ft, Puritan Bennett
0004-00-0079-14 Air Gas Supply Hose, 15 ft, DISS Female
0004-00-0080-13 VAC Gas Supply Hose, 15 ft, Ohmeda
0004-00-0080-14 VAC Gas Supply Hose, 15 ft, Chemetron
0004-00-0080-15 VAC Gas Supply Hose, 15 ft, Puritan Bennett
0004-00-0080-16 VAC Gas Supply Hose, 15 ft, DISS Female
0004-00-0081-11 EVAC Gas Supply Hose, 15 ft, Ohmeda
0004-00-0081-12 EVAC Gas Supply Hose, 15 ft, Chemetron
0004-00-0081-13 EVAC Gas Supply Hose, 15 ft, Puritan Bennett
0004-00-0081-14 EVAC Gas Supply Hose, 15 ft, DISS Female
0004-00-0081-31 EVAC DISS to VAC Ohmeda Gas Supply Hose, 15 ft
0004-00-0081-32 EVAC DISS to VAC Chemetron Gas Supply Hose, 15 ft
0004-00-0081-33 EVAC DISS to VAC Puritan Bennett Gas Supply Hose, 15 ft
0004-00-0081-34 EVAC DISS to VAC DISS Female Gas Supply Hose, 15 ft
Manuals and
Reference
Cards
046-019163-00 A8/A9 Disinfection/Cleaning Card
046-019101-00 A8/A9 Pre-Operation Checklist(English)
Mounting
Accessories
115-066029-00 Bracket for N12/15/17/ePM15, variable
115-066074-00 Bracket for N12/15/17/ePM15, fixed
115-069443-00 Bracket for N19/N22,fixed
034-000460-00 GCX 12" x 12" Articulating Arm with Tray
0436-00-0259 Mount, Suction Canister
008-000468-00 CPU Mount 3-4.5”/7.6-11.4 cm wide
008-000468-01 CPU Mount 1.5-3”/3.8-7.6 cm wide
008-000468-02 CPU Mount 4.5-7”/11.4-17.8 cm wide
008-000468-03 CPU Mount 7-9.5”/17.8-24.1 cm wide
115-069445-00 Top shelf upgrade kit
115-070794-00 Bracket kit for N15/17, fixed
115-074073-00 Bracket kit for N12, fixed
034-000288-00 Bracket for CIS system
Networking
and USB
Storage
0012-00-1274-06 CAT 5 Ethernet Cable, Patch, STP, 3' (0.91 m)
0012-00-1392-06 CAT 5 Ethernet Cable, Crossover, STP, 6' (1.83 m)
023-000361-00 USB Wired Mouse
023-001673-00 USB Storage Device, 8GB
TYPE PART NUMBER DESCRIPTION

Mindray A9 Specifications

General

Type	Anesthesia Workstation
Integrated Gas Analysis	Yes
Backup Battery	Yes
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 55°C
Battery Type	Lithium-ion
Ventilation Modes	Volume Control, Pressure Control, SIMV, Manual Ventilation
Display	Touchscreen
Patient Monitoring	ECG, SpO2, NIBP, EtCO2, Temperature
Connectivity	Ethernet, USB
Portability	Mobile (with wheels)
Battery Life	Minimum 90 minutes (typical)
Altitude	Up to 3000 meters
Power Supply	100-240 VAC, 50/60 Hz
Charging Time	Approximately 4 hours
Storage	Internal storage for patient data and system logs
Supported Languages	Multiple languages
Certifications	CE, FDA
