C-10 Barcode Reader
Tips: Hold the digital imager reader between two and nine inches (depending on
symbol density) from the symbol, centering the aiming pattern cross hairs on the
symbol.
The aiming pattern is smaller when the digital imager reader is closer to the symbol
and larger when it is farther from the symbol. Scan symbols with smaller bars or
elements (mil size) closer to the digital imager reader, and those with larger bars or
elements (mil size) farther from the digital imager reader.
The digital imager reader can also read a barcode presented within the aiming pattern
but not centered. The top examples in show acceptable aiming options, while the
bottom examples cannot be decoded.
C.2.5 Scanning in Hands-Free Mode
The optional Intellistand adds greater flexibility to scanning operation. When the digital
imager reader is seated in the stand’s “cup,” the digital imager reader’s built-in sensor
places the digital imager reader in hands-free mode. When the digital imager reader is
removed from the stand it operates in its normal hand-held mode.
Use the Intellistand’s adjustment knobs to adjust the height and angle of the
digital imager reader.
1.
Reader holder (cup)
2.
Angle adjustment knob
3.
Height adjustment knob
