S
truc
ture
and Ass
embly/Disassembl
y
8-
19
3.
Remove the caps on the control panel.
Pull out the cap upwards
. Caps for: small encoder but
ton (Zoom),
TCG cap (8 caps), large
encoder button (Aut
o Correct), large enc
ode button (iT
ouch).
4.
Disassemble t
he buzzer
.
Large encoder
button (Auto
Correct)
Large encoder
button (iT
ouch)
Small encoder
button (Zoom)
TGC cap (8 caps)
M3X6 cross slot s
crew (6 screws)
148
150
