S
truc
ture
and Ass
embly/Disassembl
y
8-
33
8.3.4
T
r
olley
Panel
Board Assembly
1.
Unscrew 10 sc
rews (M4 X 12 cross panhead screw) on the ba
ck of trolley panel’s base, and
take out the panel cover
.
2.
Remove the rotatable clasp
Unscrew 2 screws
on the fixing bracket
for the spring (M4 X 12 cros
s panhead screws), and
take out the fixing bracket and the s
pring.
M4X16 cross panhead with the pad and the clip (4 screws)
M4X12 cross panhead screw
(10 screws)
