S
truc
ture
and Ass
embly/Disassembl
y
8-
39
6.
Remove
gas spring
Unscrew 6 screws
(M5 X 25
Allen
screw with t
he pad and the clip) on the connect
ing base of
the gas spring.
Remove the latch of
the gas spring at the bottom
of the lifting column. T
ake out the gas spring
upwards.
M5X25
Allen screw with the
pad or the clip (6 screws)
Connecting base
Remove the connecting rod t
owards arrow’s direction
S
pring of the connecting r
od
168
