External Linearization with the Factory-Dened
Weight (Default Weights)
Setup Information – This function is accessible only if the software and the functionality of the
connected weighing platform permit this operation.
– External linearization when weighing in legal metrology is only possible when
the menu access switch is open.
– The J key must be assigned the “External linearization“ function, see
“Function Allocation of the J Key for Linearization and Setting/Deleting the
Preload.“
– Activating the display of geographical data has no eect on this function.
3
Once linearization has been completed, the J key must be reallocated back to
its original function in the Setup menu, e.g. external calibration/adjustment with
default weights.
Procedure t For scales used in legal metrology, slide the menu access switch to the left
(= “open“ position).
y The display goes out and the device restarts. Then weighing mode is active.
t Press ( to unload and zero the scale.
t Press J to start the external linearization.
y The display “L.EXT.D“ appears briey.
Additional steps are explained in “External Linearization with User-Dened
Weights.“
